Diesel Screw Compressors

FS Curtis Trailer Mounted Diesel Screw Compressors

Designed for towable mobility, trailer mounted diesel air compressors are often the best option for applications requiring portable or especially hardy equipment.

Enerquip's trailer mounted diesel air compressor models can be easily converted into box type configuration for truck mounted applications.

Each compressor model's fuel consumption and noise emission levels are among the best of its class. Furthermore, all models are based on well-proven designs that are market leaders in Japan, and already widely distributed throughout the world.

Thousands of these diesel units are already working under the most demanding conditions in construction, mining, and industrial applications.

With a comprehensive array of features, the Enerquip supplied FAC Series represents outstanding value for money in capital investment terms, with low whole-of-life operating costs.

Series Specifications

The FAC Series from FS-Curtis comprises a range of heavy duty, portable diesel air compressors offering superior efficiency, quality and reliability in an environmentally responsible manner. Each model's fuel consumption and noise emission levels are amongst the best in class. There is a wide selection of 34 models including box and trailer type configurations, continuous duty outputs from 1.2 to 36 m3/min (55 to 1,300 cfm), and working pressures from 7 to 24 bar (100 to 350 psi).
FS Curtis
Model
FAD
cfm
Rated Pressure
bar
Max. Pressure
bar
Aftercooler Engine Fuel Consumption
L/h @ 100% Load
Noise Level
@ 7m
Weight
kg
FAC-52P 185 6.9 9 n/a Yanmar 4TNV88-BDHKS 9.5 72 960
FAC-75P 265 6.9 9 option available Yanmar 4TNV98T-NKV 15 69 1460
FAC-110P 390 7 9 option available Izuzu DD-4BG1T 22 69 2040
FAC-185P 655 7 9 option available Hino J08C-V 32 72 3200
FAC-212P 750 7 9 n/a Hino J08C-UT 37.6 74 3300
FACE-250P 885 8.6 10 n/a Mitsubishi 6D24-TE1 59 80 4600
FACF-150P 530 10.5 12.5 n/a Hino J08C-V 32 72 3240
FACF-235P 830 10.3 12.7 n/a Mitsubishi 6D24-TE1 59 80 4600
FACG-125P 830 12.7 15.5 n/a Hino J08C-V 32 74 3240
FACG-212P 830 12.7 15.2 n/a Mitsubishi 6D24-TE1 59 80 4600
